Epson EB-535W User Manual

Submenu Function
Sleep Mode
When set to On, this automatically stops projection when no
image signal is being input and no operations are carried out for a
specified length of time. Also, if no image signal is input for a
specified length of time, the lamp dims until the power turns off.
When an image signal is input, the projector returns to normal
operating status.
Sleep Mode Tim-
er
When Sleep Mode is set to On, you can set the time before the
projector automatically turns off within a range of 1 to 30
minutes.
A/V Mute Timer
When set to On, this turns off the power automatically 30
minutes after A/V mute is enabled. Also, if A/V mute is enabled
and a specified length of time has passed, the lamp dims until the
power turns off. When A/V mute is disabled, the projector
returns to normal operating status.
Standby Mode
If you set Communication On, you can perform the following
operations even if the projector is in standby mode.
 Monitor and control the projector from a computer over the
network
 Output audio and images to an external device (only when
A/V Output is set to Always On)
 Output audio from the projector's speaker (only when A/V
Output is set to Always On)
a
Set Connection Mode to Advanced when
monitoring and controlling the projector over
wireless LAN.
s Network - Wireless LAN - Connection
Mode p.115
ECO Display
When set to On, when the lamp brightness changes from normal
to low or low to normal, leaf icons are displayed at the bottom-
left of the projected screen to indicate the power-saving status.
Submenu Function
Reset
You can reset all adjustment values on the ECO menu to their
default settings, except for Standby Mode. See the following to
return all menu items to their default settings.
s "Reset Menu" p.135
Info Menu (Display Only)
Lets you check the status of the image signals being projected and the status
of the projector. Items that can be displayed vary depending on the source
currently being projected. Depending on the model used, some input
sources are not supported.
s "Automatically Detect Input Signals and Change the Projected Image
(Source Search)" p.43
List of Functions
134

Epson EB-535W Specifications

General

Number of colors	1.07 billion colors
Native aspect ratio	16:10
Projection distance	0.5 - 1.2 m
Vertical scan range	50 - 85 Hz
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	16000:1
Screen size compatibility	53 - 116 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-15 - 15 °
Projector brightness (economic mode)	1900 ANSI lumens
Focus	Manual
Throw ratio	0.48 - 0.65:1
Focal length range	6.4 mm
Lamp power	215 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
HD-Ready	Yes
Video processing	10 bit
Analog signal format system	NTSC, NTSC 4.43
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	37 dB
Country of origin	China
Noise level (economic mode)	29 dB
RMS rated power	16 W
Placement	Desktop
Product type	Short throw projector
Product color	White, Grey
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.28 W
Power consumption (typical)	298 W
Power consumption (PowerSave)	221 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, VGA
Bundled software	iProjection, Epson Projector Management
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	60 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	85286200
Quantity per pallet layer (UK)	6 pc(s)
USB display function	3 in 1: Image / Mouse / Sound
Sustainability certificates	TCO

Weight and Dimensions

Depth	315 mm
Width	344 mm
Height	94 mm
Weight	3700 g
Package depth	497 mm
Package width	386 mm
Package height	215 mm
Package weight	5860 g
