Introduction
9
Figures of Installation Dimensions
100mm
500mm 500mm
46.5mm
Caution
When installing the projector, make sure there is a gap between the wall and the projector's air exhaust
and intake vents. (See figure
above)
c
Leaving a gap of approximately 100 mm from the ceiling to the top of the wall plate makes it easier
to install and remove the projector. (See figure
above)
To Next Page
