Setting the Projector
80
d
Make necessary settings on the Multi-Projection menu
For details on making settings, see the projector's User's Guide.
Edge Blending
Black Level
Adjust the image overlapping section to create a seam-
less image.
Scale
Set the magnification and splicing position for the im-
age.
Light Source Mode Adjust the brightness of the entire image. Select Cus-
tom, and then adjust the Brightness Level based on the
darkest projector.
Color Uniformity
Color Matching
RGBCMY
Adjust the color of the image for each projector so that
the entire image looks uniform.
When using the EB-725W/EB-735F/EB-720
a
Turn on the projector
b
Press the [Menu] button
Using the Remote Control Using the Control Panel
c
Make the necessary settings from the following menus
For details on making settings, see the projector's User's Guide.
Image - Color Mode
(Press the [Color Mode] button on the
remote control to execute)
Select the same item for each projector so that the color
of the entire image looks uniform.
Operation - Light Source Brightness
Control - Light Source Mode
Adjust the brightness of the entire image. Select Cus-
tom, and then adjust the Brightness Level based on the
darkest projector.
Management - Color Uniformity
Image - RGBCMY
Adjust the color of the image for each projector so that
the entire image looks uniform.
To Next Page
