About This Installation Guide
3
Example Workflow for Replacement Installations
You can replace the projector using the following workflow. The mount or your projector may differ from the
illustrations. For details on handling and adjusting the mount, see the Installation Guide for the projector that
has already been installed or for the wall mount.
a
Remove the old projector
•
Remove the end cap (also remove the wall plate cover if necessary)
•
Remove the adjustment unit from the setting plate
b
Install the new projector
•
Remove the adjustment unit from the old projector and attach it to the new projector
•
Attach the adjustment unit to the setting plate
c
Fine-tune the image
While projecting an image, fine-tune the position of the image using the adjustment dial on the mount
and the projector's correction features
d
Attach the end cap
