Introduction
8
Part Name Application
M3 x 6 mm cross recessed
head shoulder screws (x4)
Secure the mini PC plate to the wall
plate.
Necessary Items
As well as the items supplied, you also need to prepare the following screws and tools.
Applicable parts Necessary items
For the wall mount
•
M10 or 3/8 inch x 60 mm anchor bolts (for securing the wall plate: at
least x4)
•
M10 screw (for securing the wall plate temporarily: x1)
•
17 mm ratchet wrench (for adjusting hexagonal axis)
•
Cables to connect to the projector
•
Devices such as mini PCs
