Installing the Wall mount
61
g
Loosen the M4 bolts (x2), and then adjust the forward/backward slide
h
Loosen the M6 bolt, and then adjust the vertical slide
i
Re-tighten the screws and bolts that you loosened in steps 3 to 8
Warning
Tighten all bolts and screws firmly. Otherwise, the product may fall and cause personal injury or
property damage.
