107
Connecting a LAN Cable
Connect with a commercially available 100BASE-TX or 10BASE-T
type LAN cable. The following illustration shows an example of the EB-
G5350/5150. Depending on the model you are using, the interface
may differ, for example there may not be an SD card slot.
Attention
To prevent malfunctions, use a category 5 shielded LAN cable.
To LAN port
To LAN port
LAN cable
(commercially available)
To Next Page
