EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480
Disassembly and Assembly CONFIDENTIAL
SEIKO EPSON 56 Revision C
3.2 Flowchart
The general disassembly procedure for the EB-S01/W01/X14G/S11/X11/S02/S02H/
X02/W02/S12/S12H/X12/W12/X14 EH-TW480 projectors is illustrated in flowchart
below. Unless otherwise specified, all reassembly should be carried out by following
the disassembly procedures in reverse, therefore reassembling procedures are omitted.
CONSUMABLES/OPTIONS
The part names in this chapter are simplified. See the
“Reference (Part Names given in the SPI) (p.116)” for the
corresponding official names.
The parts in yellow are target parts in their category. They
are explained in details in the corresponding sections so as to
reach the parts in the shortest way.
The parts in white are those which are required to be
removed to reach the parts in yellow.
Start
“ 3.3.2 Lamp (p60)” “ 3.3.1 Air Filter (p59)”
“ 3.3.5 Upper Case
(assembly) (p62)”
“ 3.3.6 MA Board
(assembly) (p74)”
“ 3.3.8 Optical
Engine (p82)”
“ 3.3.8.2 Focus Ring /
Zoom Ring (p85)”
“ 3.3.4 Front Foot
(p62)”
“ 3.3.3 Rear Foot (p61)”
To Next Page
