EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480
Disassembly and Assembly CONFIDENTIAL
SEIKO EPSON 60 Revision C
3.3.2 Lamp
1. Loosen the screw and remove the Lamp Cover.
Figure 3-2.
2. Loosen the two screws and remove the Lamp.
Figure 3-3.
Standard Operation Time - Min.
This part is designated as the Safety Device.When removing/
replacing the part for repair, be sure to refer to “3.4 Safety Check
after Servicing (p.103)”. According to the instructions in it,
handle the part and perform the procedure after servicing.
To Next Page
