EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480
Disassembly and Assembly CONFIDENTIAL
SEIKO EPSON 63 Revision C
After removing the Upper Case, DO NOT TOUCH the red-circled points shown in the figure because a high voltage is applied there.
Don’t touch here!!
Don’t touch here!!
[Nichicon Board’s Case]
[Panasonic Board’s Case]
