Epson EH-LS500W - Supported Resolutions; Unique Aspect

Appendix
93
Supported Resolutions
If the projector receives higher resolution signals than the resolution of the projector panel, the image quality
may be degraded.
The projector supports signals marked with a check symbol.
PC
Signal For-
mat
Resolution
(Dots)
V Sync
(Hz)
Dotclk
(MHz)
HDMI
RGB YCbCr
4:4:4 4:2:2 4:2:0
8
10, 12 8 10, 12 8 10, 12 8 10, 12
VGA60 640 480 60 25.175
Unique Aspect
Signal For-
mat
Resolution
(Dots)
V Sync
(Hz)
Dotclk
(MHz)
HDMI
RGB YCbCr
4:4:4 4:2:2 4:2:0
8
10, 12 8 10, 12 8 10, 12 8 10, 12
21:9 2560 1080 60 198.000
SD
Signal For-
mat
Resolution
(Dots)
V Sync
(Hz)
Dotclk
(MHz)
HDMI
RGB YCbCr
4:4:4 4:2:2 4:2:0
8
10, 12 8 10, 12 8 10, 12 8 10, 12
SDTV (480i) 720 480 59.94 13.500
SDTV (576i) 720 576 50 13.500
SDTV (480p) 720 480 59.94 27.000
SDTV (576p) 720 576 50 27.000
