Name Function
D
[w][v] buttons
Displays the Keystone screen allowing you to correct
Keystone distortion in vertical and horizontal
directions.
s "Correcting manually" p.35
If pressed when the Configuration menu or the Help
screen is displayed, these buttons select menu items and
setting values.
s "Using the Configuration Menu" p.72
s "Using the Help" p.82
E
[Help] button
Displays and closes the Help screen which shows you how
to deal with problems if they occur.
s "Using the Help" p.82
F
[Esc] button
Stops the current function.
If pressed when the Configuration menu is displayed, it
moves to the previous menu level.
s "Using the Configuration Menu" p.72
G
[a][b] buttons
Adjusts the speaker volume.
[b] Increases the volume.
[a] Decreases the volume.
s "Adjusting the Volume" p.42
Corrects keystone distortion in the horizontal direction
when the Keystone screen is displayed.
s "H/V-Keystone" p.35
If pressed when the Configuration menu or the Help
screen is displayed, these buttons select menu items and
setting values.
s "Using the Configuration Menu" p.72
s
"Using the Help" p.82
H
[Menu] button
Displays and closes the Configuration menu.
s "Using the Configuration Menu" p.72
Name Function
I
[Screen Fit] button
(EB-W16 only)
Adjusts the projected image so that it fits the screen frame.
s "Automatically Adjust to Fit into the Screen Frame
(Screen Fit) (EB-W16 only)" p.38
This button is disabled when the projector is suspended
from a ceiling.
J
[Focus Help] button
(EB-W16 only)
Opens the dialog to provide focus adjustment assistance.
s "Correcting the Focus" p.41
Part Names and Functions
