Epson EH-TW550 User Manual

Notations Used in This Guide ........................ 2
Introduction
Projector Features .......................................... 7
Project Realistic 3D Images........................................ 7
Quick and Easy Set up, Projection, and Storage..........................7
Connecting with a USB cable and projecting (USB Display)................7
Detecting projector movements and automatically correcting image distortion . . 7
Horizontal keystone adjuster (EH-TW550/EH-TW510 only) . ................7
Focus help (EB-W16 only) ....................................... 8
Automatically adjust to fit into the screen frame (Screen Fit) (EB-W16 only).....8
Useful Functions for Projecting Images................................8
Increasing projection content in wide (WXGA) screen....................8
Making the most of the remote control.............................8
Enlarge and project your files with the Document Camera .................8
Connect a USB storage device and project movies and images (PC Free).......9
Enhanced security functions.....................................9
Part Names and Functions .................................. 10
Front/Top...................................................10
Rear.......................................................11
Base ...................................................... 12
Control Panel................................................13
Remote Control ...............................................15
Replacing the remote control batteries.............................17
Remote control operating range.................................18
Preparing the Projector
Installing the Projector ..................................... 20
Installation Methods ...........................................20
Installation methods .........................................20
Screen Size and Approximate Projection Distance.......................21
Connecting Equipment ..................................... 22
Connecting a Computer .........................................22
Connecting Image Sources.......................................23
Connecting USB Devices .........................................25
Connecting External Equipment (EB-W16 only).........................26
Basic Usage
Projecting Images ......................................... 28
From Installation to Projection .....................................28
Automatically Detect Input Signals and Change the Projected Image (Source Search)
..........................................................29
Switching to the Target Image by Remote Control.......................30
Projecting with USB Display......................................30
System requirements.........................................30
Connecting for the first time....................................31
Uninstalling ...............................................32
Adjusting Projected Images ................................ 34
Correcting Keystone Distortion ....................................34
Correcting automatically......................................34
Correcting manually.........................................35
Automatically Adjust to Fit into the Screen Frame (Screen Fit) (EB-W16 only) . . . . . 38
Adjusting the Image Size ........................................40
Adjusting the Image Position .....................................41
Adjusting the Horizontal Tilt......................................41
Correcting the Focus...........................................41
Adjusting the Volume..........................................42
Selecting the Projection Quality (Selecting Color Mode)...................42
For EB-W16 ................................................42
For EH-TW550/EH-TW510 ......................................43
Setting Auto Iris..............................................43
Changing the Aspect Ratio of the Projected Image.......................44
Changing methods..........................................44
Changing the aspect mode ..................................... 45
Contents
3

Epson EH-TW550 Specifications

General

Matrix size	0.59 \
Matrix type	3-panel (p-Si TFT active)
Native aspect ratio	16:10
Projection technology	3LCD
Contrast ratio (typical)	5000:1
Screen size compatibility	33 - 318 \
Projection distance (tele)	1.1 - 10.8 m
Projection distance (wide)	0.9 - 9 m
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-30 - 30 °
Focus	Manual
Offset	10 %
Focal length range	1.58 - 1.72 mm
Aperture range (F-F)	17 - 20
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
Full HD	No
HD-Ready	Yes
Color modes (2D)	Cinema, Dynamic
Video processing	17 bit
Video color modes	Cinema, Dynamic, Game, Living room
Supported 3D formats	Frame packing, Side by side, Top and bottom
HDMI version	1.4
Composite video in	1
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
2D/3D frequency image	240 Hz
Noise level (economic mode)	29 dB
RMS rated power	2 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Market positioning	Home cinema
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.47 W
Power consumption (typical)	311 W
Power consumption (economy mode)	258 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	243 mm
Width	325 mm
Height	77 mm
Weight	2600 g
