Registering the 3D Glasses to the projector (pairing)
When viewing 3D images, the projector communicates with the 3D Glasses.
To communicate correctly, the 3D Glasses have to be registered to the
projector. This is known as "pairing".
Perform pairing in the following situations.
When turning on the 3D Glasses for the first time
Pairing starts automatically when the power is turned on.
When you cannot view 3D images correctly
Follow the steps below to perform pairing.
a
Turn on the projector.
b
Press the [Source Search] button on the control panel or the
remote control, and then select HDMI.
c
Turn on the 3D Glasses by sliding the [Power] switch to On.
The indicator turns on for several seconds, and then turns off.
d
Hold down the [Pairing] button on the 3D Glasses for three
seconds.
The indicator flashes alternately green and red. If pairing is
successful, the indicator turns green for ten seconds and then turns
off.
a
If pairing is not successful, the 3D Glasses turn off.
When performing pairing, make sure the distance between the
projector and the 3D Glasses is less than three meters.
You can pair up to 50 3D Glasses with this projector.
Viewing 3D images
a
Connect the projector to the playback device with an HDMI cable.
a
3D images can only be viewed when HDMI is being input.
Prepare an HDMI cable that supports 3D signals.
See the following for more information on connecting the
HDMI cables.
s "Connecting Equipment" p.22
b
Turn on the playback device and the projector, and then project
the image.
If no image is displayed, press the [Source Search] button on the
control panel or the remote control, and then select HDMI.
Projection Functions
49

Table of Contents

Other manuals for Epson EH-TW550

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EH-TW550 and is the answer not in the manual?

Epson EH-TW550 Specifications

General IconGeneral
Matrix size0.59 \
Matrix type3-panel (p-Si TFT active)
Native aspect ratio16:10
Projection technology3LCD
Contrast ratio (typical)5000:1
Screen size compatibility33 - 318 \
Projection distance (tele)1.1 - 10.8 m
Projection distance (wide)0.9 - 9 m
Projector native resolutionWXGA (1280x800)
Keystone correction, horizontal-30 - 30 °
FocusManual
Offset10 %
Focal length range1.58 - 1.72 mm
Aperture range (F-F)17 - 20
Lamp power200 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source4000 h
Service life of light source (economic mode)5000 h
Full HDNo
HD-ReadyYes
Color modes (2D)Cinema, Dynamic
Video processing17 bit
Video color modesCinema, Dynamic, Game, Living room
Supported 3D formatsFrame packing, Side by side, Top and bottom
HDMI version1.4
Composite video in1
USB connector typeUSB Type-A, USB Type-B
USB 2.0 ports quantity2
2D/3D frequency image240 Hz
Noise level (economic mode)29 dB
RMS rated power2 W
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorBlack
Market positioningHome cinema
Cable lock slot typeKensington
Power sourceAC
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.47 W
Power consumption (typical)311 W
Power consumption (economy mode)258 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth243 mm
Width325 mm
Height77 mm
Weight2600 g
