Epson EH-TW5500 Service Manual

EH-TW3500/4500/5500 Product Description CONFIDENTIAL
SEIKO EPSON 13 Revision A
Power Consumption
100-120V Area
(JAPAN, USA, etc.)
Lamp (ON)
Normal 282 W 297 W
Eco 231 W 246 W
Standby 0.2 W
220-240V Area
(Europe, etc.)
Lamp (ON)
Normal 269 W 284 W
Eco 222 W 236 W
Standby 0.4 W
Rated Voltage & Current
100 - 240 V AC 50/60 Hz
3.2 - 1.4 A
100 - 240 V AC 50/60 Hz
3.3 - 1.5 A
Size
Excluding feet and Projection Lens
Unit: mm
360 (D) x 450 (W) x 136 (H)
Maximum Dimension 360 (D) x 450 (W) x 145 (H)
Weight Approx. 16.1 lbs/ 7.3 kg Approx. 16.5 lbs/ 7.5 kg
Fan noise
High Brightness mode 30 dB 30 dB (TBD)
Low Brightness mode 22 dB 22 dB (TBD)
Model
EH-TW3500 EH-TW4500 EH-TW5500
Item

Epson EH-TW5500 Specifications

General

Brand	Epson
Model	EH-TW5500
Category	Projector
Language	English
