EH-TW3500/4500/5500 Disassembly and Assembly CONFIDENTIAL
SEIKO EPSON 99 Revision A
3.5 Reference (Part Names given in the SPI)
Part names used in this chapter are rewritten so as to be read easily in sentences. The
part names used in this manual and the corresponding official names given in SPI are
listed below.
Part Names given in the SPI
Names used in this Chapter Official Name given in SPI
AC Cable CABLE,AC
Air Filter Assembly AIRFILTER
Air Filter Cover LID,AIR FILTER;B
Auto Iris AUTO IRIS ASSY
Cable C170 CABLE,C;170
Cable TH Cable,TH
CF Frame FRAME CF ASSY.
CF Motor MOTOR CF ASSY.
CF Plate PLATE,CONDUCTION,CF
CF Switch SW CF ASSY.
Cushion LED CUSHION,LED
Decoration Plate L DECORATION PLATE;L
Decoration Plate R DECORATION PLATE;R
Diffusion Plate PLATE,DIFFUSION
DR Board
PRINTED CIRCUIT BOARD
ASSEMBLY;DR_S2
Enter Button BOTTON,SW,SIDE;ENTER,B
EX Duct PS Duct,Exhaust;PS
EX Fan FAN,EXHAUST
EX Fan Cushion Cushion,Exhaust Fan
EX Seal SEAL,EX
Fan Holder HOLDER,FAN
Fan sheet SHEET,HOLDER,FAN.
Focus Ring FOCUS RING;S
Foot Holder HOLDER FOOT;A
Foot Rubber RUBBER FOOT;A
Front Foot Foot;A38,silver
Gasket (1) GASKET 6_10_10
Gasket (2) GASKET 10_10_20
Gasket (3) GASKET 2_3_35
Gasket (4) GASKET 10_10_20
IF Case CASE,IF;B
IF Label LABEL,IF;B
IF Shading Sheet SHEET,SHADE,IF
Inner EX Duct DUCT,EXHAUST,INNER
Inner Upper Cover COVER,UPPER,INNER
INT Cushion Cushion,Floating;a
INT Fan FAN,INTAKE
INT Seal A SEAL,INTAKE;A
INT Seal B1 SEAL,INTAKE;B1
INT Seal B2 SEAL,INTAKE;B2
INT Seal C SEAL,INTAKE;C
Lamp LAMP,ASSEMBLY;AS
Lamp Cover LID ASSY,LAMP;B4000
Lamp Fan FAN,LAMP
Lamp Fan Cover COVER,LAMP FAN
Lamp Fan Duct DUCT,LAMP FAN
Lamp Latch Cover LATCH,LID,LAMP
Latch Spring SPRING,LATCH,LID LAMP
LED Lens LENS,LED;PW
LG Spring SPRING,LG FASTEN
Names used in this Chapter Official Name given in SPI
