EH-TW3500/4500/5500 Troubleshooting CONFIDENTIAL
SEIKO EPSON 39 Revision A
TROUBLE SHOOTING ON OTHER ABNORMALITY
Error Status Faulty part/part name Cause Remedy Reference
Smoke/Abnormal odor
Lamp Burn on dust from heat. Clean the area around Lamp to remove dust or the like.
"3.3.2 Lamp (p55)"
Cables Burn on cables from heat. If burn on cables occurs, replace them with new ones.
PS Ballast Burn on a circuit board from heat. Replace the PS Ballast.
"3.3.15 PS Ballast (p92)"
To Next Page
