Epson FX-890II User Manual

10. Turn the ribbon-tightening knob to help feed the ribbon into place.
!
Caution:
The ribbon should not be twisted or creased.
11. Replace the printer cover by inserting the front tabs into the slots on the printer and lowering the
cover into place.
Cut-Sheet Feeder
Two types of optional cut-sheet feeders are available for use with your printer as shown below:
Single-bin cut-sheet feeder: FX-890II/FX-890IIN C80637*
FX-2190II/FX-2190IIN C80639*
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Options and Consumables 123

Epson FX-890II Specifications

General

Color	No
Character sets	ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8
Character pitch	10 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum print speed (LQ)	115 cps
Maximum print speed (draft)	463 cps
Maximum printing width (columns)	80
Product color	Black
Page description languages	ESC P, PPDS
Sound pressure level (printing)	55 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Mean time between failures (MTBF)	20000 h
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Cut sheet thickness range	0.12 - 0.46 mm
Continuous paper thickness range	0.46 - 0.46 mm
Standard interfaces	Parallel, USB 2.0

Weight and Dimensions

Depth	376 mm
Width	437 mm
Height	177 mm
