Epson FX-890II User Manual

Note:
You cannot change the language by the ItemU (Pitch) button.
4. Press the Set (Tear Off/Bin) button to select the desired language.
The printer prints a message asking if you wish to print all of the current settings.
Note:
The language you select is also effective when you are entering the lock-out setting mode or
bidirectional adjustment mode.
5. If you want to print the current settings, press the Set button. If you want to bypass printing of the
current settings, press the ItemD button or the ItemU button.
The printer prints the first menu and the current value of the menu.
6. Press the ItemD button or the ItemU button to select the menu parameters which you wish to
change. Press the Set button to scroll through the values within the selected parameter until you
find the desired setting. After setting the selected parameter to the desired setting, you may either
continue to make changes to other parameters by pressing the ItemD button or the ItemU button,
or exit the default-setting mode by pressing the Menu (Pitch and Tear Off/Bin) buttons.
Note:
You cannot change the setting value to the previous item. You have to press the Set button until the
value you want is selected.
7. After you finish settings, press the Menu (Pitch and Tear Off/Bin) buttons.
The Menu lights (both of the Tear Off/Bin lights) turn off and the printer exits the default-setting
mode.
The settings you made is saved as new default value.
Note:
If you turn off the printer prior to exiting default-setting mode, any changes you may have made are
canceled and not saved.
Lock-Out Mode
You can restrict the use of buttons on the control panel by using the lock-out mode.
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Control Panel 98

Epson FX-890II Specifications

General

Color	No
Character sets	ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8
Character pitch	10 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum print speed (LQ)	115 cps
Maximum print speed (draft)	463 cps
Maximum printing width (columns)	80
Product color	Black
Page description languages	ESC P, PPDS
Sound pressure level (printing)	55 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Mean time between failures (MTBF)	20000 h
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Cut sheet thickness range	0.12 - 0.46 mm
Continuous paper thickness range	0.46 - 0.46 mm
Standard interfaces	Parallel, USB 2.0

Weight and Dimensions

Depth	376 mm
Width	437 mm
Height	177 mm
