Epson FX-890II User Manual

Loading Single Sheets
You can load ordinary single sheets and envelopes one at a time from the rear and front bypass tray of
the printer, using the sheet guide.
You can also load single-sheet paper using an optional cut-sheet feeder and sheet guide. See “Front
sheet guide” on page 45 for more information.
Available paper types
The table below shows the types of paper you can load and the paper slots you can use with each paper
type. See “Adjusting the Paper Thickness Lever” on page 19 for instructions on how to adjust the
paper-thickness lever.
Paper type Available paper slot(s)
Ordinary paper front and rear
Multipart forms
(carbonless)
2 parts (original and one copy) front and rear
3 parts (original and two copies)
4 parts (original and three copies)
5 parts (original and four copies)
6 parts (original and five copies)
Envelopes rear
Note:
Do not load paper that is curled or has been folded.
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Paper Handling 44

Epson FX-890II Specifications

General

Color	No
Character sets	ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8
Character pitch	10 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum print speed (LQ)	115 cps
Maximum print speed (draft)	463 cps
Maximum printing width (columns)	80
Product color	Black
Page description languages	ESC P, PPDS
Sound pressure level (printing)	55 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Mean time between failures (MTBF)	20000 h
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Cut sheet thickness range	0.12 - 0.46 mm
Continuous paper thickness range	0.46 - 0.46 mm
Standard interfaces	Parallel, USB 2.0

Weight and Dimensions

Depth	376 mm
Width	437 mm
Height	177 mm
