Epson FX-890II User Manual

Note:
When uninstalling EPSON Status Monitor 3 from a multi-user Windows XP environment, remove the
shortcut icon from all clients before uninstalling. You can remove the icon by clearing the Shortcut Icon
check box in the Monitoring Preferences dialog box.
Uninstalling the printer driver and EPSON Status Monitor 3
1. Quit all applications.
2. Right-click the Start menu, and then click Control Panel.
3. Click Uninstall a program (Windows 10, 8, 8.1, 7, or Vista) or double-click the Add or Remove
Programs icon (Windows XP).
4. Select the desired printer, then right click Uninstall/Change.
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Printer Software 86

Epson FX-890II Specifications

General

Color	No
Character sets	ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8
Character pitch	10 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum print speed (LQ)	115 cps
Maximum print speed (draft)	463 cps
Maximum printing width (columns)	80
Product color	Black
Page description languages	ESC P, PPDS
Sound pressure level (printing)	55 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Mean time between failures (MTBF)	20000 h
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Cut sheet thickness range	0.12 - 0.46 mm
Continuous paper thickness range	0.46 - 0.46 mm
Standard interfaces	Parallel, USB 2.0

Weight and Dimensions

Depth	376 mm
Width	437 mm
Height	177 mm
