Epson L6570 Series User Manual

Items Settings and Explanation
Number of search entries Specify the number of search entries between 5 and 500. The specied number of
the search entries is saved and displayed temporarily. Even if the number of the
search entries is over the specied number and an error message appears, the
search can be completed.
User name Attribute Specify the attribute name to display when searching for user names. Enter
between 1 and 255 characters in Unicode (UTF-8). The
rst
character should be a-z
or A-Z.
Example: cn, uid
User name Display Attribute Specify the attribute name to display as the user name. Enter between 0 and 255
characters in Unicode (UTF-8). The rst character should be a-z or A-Z.
Example: cn, sn
Fax Number Attribute Specify the attribute name to display when searching for fax numbers. Enter a
combination of between 1 and 255 characters using A-Z, a-z, 0-9, and -. The
rst
character should be a-z or A-Z.
Example: facsimileTelephoneNumber
Email Address Attribute Specify the attribute name to display when searching for email addresses. Enter a
combination of between 1 and 255 characters using A-Z, a-z, 0-9, and -. The rst
character should be a-z or A-Z.
Example: mail
Arbitrary Attribute 1 - Arbitrary
Attribute 4
You can specify other arbitrary attributes to search for. Enter between 0 and 255
characters in Unicode (UTF-8). The rst character should be a-z or A-Z. If you do
not want to search for arbitrary attributes, leave this blank.
Example: o, ou
Checking the LDAP Server Connection
Performs the connection test to the LDAP server by using the parameter set on LDAP Server > Search Settings.
1.
Access Web Cong and select the Network tab > LDAP Server > Connection Test.
2.
Select Start.
e
connection test is started.
Aer
the test, the check report is displayed.
LDAP Server Connection Test References
Messages Explanation
Connection test was successful. This message appears when the connection with the server is successful.
Administrator Information > Settings to Use the Printer > Making Contacts Available
383

Epson L6570 Series Specifications

General

Print Technology	PrecisionCore Heat-Free Technology
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scanner Type	Flatbed color image scanner
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Functions	Print, Scan, Copy, Fax
Fax Function	Yes
Print Speed (Black/Color)	25 ppm / 25 ppm
Duplex Printing	Yes
Display	4.3" color touchscreen
Mobile Printing	Apple AirPrint, Mopria Print Service
Paper Sizes	A4, A5, A6, B5, Letter, Legal
Ink Tank Capacity	Color: 70 mL each (Cyan, Magenta, Yellow)
