Epson RC700 User Manual

Maintenance 4. Backup and Restore
128 RC700 / RC700-A Rev.23
4.3 Backup
Backup the Controller status from the EPSON RC+ 7.0.
(1) Select EPSON RC+ 7.0 menu-[Tools]-[Controller] to display the [Controller Tools]
dialog.
(2) Click the <Backup Controller…> button to display the [Browse For Folder] dialog.
(3) Specify the folder to save the backup data. Create a new folder if desired.
(4) Click the <OK> button. A folder is created in the specified folder containing the
backup data with a name in the following format.
B_ RC700_ serial number_ date status was saved
→ Example: B_RC700_12345_2013-10-29-092951
CAUTION
■
Do not edit the backup files. Otherwise, operation of the robot system after data
restoration to the Controller is
not assured.

Epson RC700 Specifications

General

Maximum Axes	16
Communication Interfaces	Ethernet, EtherNet/IP, PROFINET, PROFIBUS, CC-Link, RS-232C, USB
Safety Standards	ISO 10218-1, ISO/TS 15066, IEC 61508, IEC 61511, ANSI/RIA R15.06
Operating System	VxWorks
Power Supply	24 VDC
