Setup & Operation 7. LAN (Ethernet Communication) Port
48 RC700 / RC700-A Rev.23
7.4 Connection of Development PC and Controller with
Ethernet
Connection between the development PC and the Controller is shown below.
(1) Connect the development PC and the Controller using the Ethernet cable.
(2) Turn on the Controller.
(3) Start EPSON RC+ 7.0.
(4) Display the [PC to Controller Communication] dialog from [Setup] in EPSON RC+
7.0 menu.
(5) Click the <Add> button.
(6) Connection “No.2” is added. Set the following and click the <Apply> button.
Name : Valid value to identify the controller to connect
IP Address : IP address for Controller to connect
(7) [Name] and [IP Address] specified in procedure (6) is displayed.

Epson RC700 Specifications

General

Maximum Axes	16
Communication Interfaces	Ethernet, EtherNet/IP, PROFINET, PROFIBUS, CC-Link, RS-232C, USB
Safety Standards	ISO 10218-1, ISO/TS 15066, IEC 61508, IEC 61511, ANSI/RIA R15.06
Operating System	VxWorks
Power Supply	24 VDC
