Maintenance 7. Maintenance Parts Replacement Procedures

RC700 / RC700-A Rev.23 153

Battery

Installation

(1)

Set a new battery.

Secure the battery with the mounting tab.

(2)

Connect the battery cables.

(3)

Insert the battery bracket and

secure it with the screws. (Mounting screw ×2)

(4)

Connect the power plug

. Turn ON the Controller and make sure that the

Controller

starts properly without any vibration or abnormal noise.


