Epson RC700 User Manual

Safety 2. Part Names and Functions
RC700 / RC700-A Rev.23 17
RC700-A-UL
(24
)
UL-Compliant Controller (RC700-A-UL):
(24) Lock out feature
This feature is used to lock out the power switch when working with the power
off such as maintenance.
A padlock for lockout should be prepared by users.
Applicable shackle diameter: 4.0 to 6.5 mm
Perform lockout using the following procedure.
(1)
Remove a fixing screw of lockout bracket A by
hand.
Screw
(2) Rotate the lockout bracket A.
A
B
(3) Set the screw removed in the step (1) to the lockout
bracket B so as not to lose it.
(4)
Put a padlock through the holes of the lockout
brackets A and B to lock.
Padlock

Epson RC700 Specifications

General

Maximum Axes	16
Communication Interfaces	Ethernet, EtherNet/IP, PROFINET, PROFIBUS, CC-Link, RS-232C, USB
Safety Standards	ISO 10218-1, ISO/TS 15066, IEC 61508, IEC 61511, ANSI/RIA R15.06
Operating System	VxWorks
Power Supply	24 VDC
