The thickness shown in the following table is the
total thickness of the fabric placed on the platen.
When using L, M, S, and XS size platens
The values shown below are for the L, M, and S
grip pad covered platens. When using a platen
without grip pad attached, or an XS size platen,
the media you are printing on can be 1.0 mm
thicker.
For T-shirts, sweatshirts, or fabric with a
thickness of up to 7.0 mm
Attach spacers a and b.
For fabric with a thickness of 5.0 to 13.0 mm
Attach spacer a only.
For fabric with a thickness of 9.0 to 17.0 mm
Attach spacer b only.
For fabric with a thickness of 15.0 to 24.0 mm
Remove spacers a and b.
See the following for details on the thickness of
the fabric.
U “Table Showing the Scale on the Label and
the Media Thickness” on page 120
When using the sleeve platen or the medium
grooved platen
For T-shirts, sweatshirts, polo shirts, or
fabric with a thickness of up to 8.0 mm
Attach spacer b only.
For fabric with a thickness of 6.0 to 14.0 mm
Remove spacers a and b.
See the following for details on the thickness of
the fabric.
U “Table Showing the Scale on the Label and
the Media Thickness” on page 120
If you do not need to change the number of
spacers, go to step 13.
SC-F2100 Series User's Guide
Basic Printing
41
