Epson SC-P600 series - Inside

Inside
A Cartridge cover
Open when replacing ink cartridges.
U “Replacing Ink Cartridges” on page 97
B Ink absorber
Absorbs ink that bleeds past the edge of the paper
during borderless printing.
C Print head
Fires ink via high density nozzles while moving left
and right to print. Do not move the print head by
hand.
Back
A AC inlet
Connects the supplied power cable.
B Airflow vents
Exhausts internal air. Do not cover the vents.
C USB port
Connects the USB cable.
D LAN port
Connects the LAN cable.
E Roll paper feeder
Paper feed slot for roll paper printing.
U “Loading Roll Paper” on page 27
F Rear support
Open to use when loading fine art media or roll
paper.
U “Loading Fine Art Media” on page 23
U “Loading Roll Paper” on page 27
