Epson SC-P600 series User Manual

o
Did you leave the front manual feed tray
open when loading roll paper?
Close the front manual feed tray, and load roll paper.
o
Fine art media may have been fed on an
angle.
After inserting fine art media, be sure the tail end of
the paper is aligned with the line on the front manual
feed tray.
U “Loading Fine Art Media” on page 23
o
Did you remove the transportation lock?
If you have not already done so, remove the
transportation lock holding the front manual feed
tray in place.
Failure to remove the transportation lock could cause
paper to jam.
Paper from the Auto Sheet
Feeder Jams During Printing
Follow the instructions on the control panel's screen,
and remove any jammed paper by following the steps
below.
c
Important:
Do not use force. Attempting to forcibly remove
jammed paper could damage the printer.
A
Slowly pull the jammed paper from the printer.
SC-P600 Series User’s Guide
Problem Solver
106

Epson SC-P600 series Specifications

General

Print Technology	Inkjet
Max Print Resolution	5760 x 1440 dpi
Number of Ink Colors	9
Connectivity	USB 2.0, Ethernet, Wi-Fi
Borderless Printing	Yes
Wi-Fi Direct	Yes
Weight	15 kg
Ink Type	Pigment ink
Media Handling	Roll Paper
Max Media Size	A3+
Display	2.7-inch color touchscreen
Minimum Ink Droplet Size	2 pl
Paper Sizes	A3+, A3, A4, A5, A6, B4, B5, Letter, Legal
Mobile Printing	Apple AirPrint, Google Cloud Print
Ink Colors	Photo Black, Matte Black, Cyan, Vivid Magenta, Vivid Light Magenta, Yellow, Light Cyan, Light Black, Light Light Black
Operating Systems	Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10, Mac OS X 10.6.8 or later
Ink Droplet Size	Variable droplet sizes as small as 2 picoliters
