Rear
A Exhaust vent
Exhausts air used to cool the printer internally.
B AC inlet
Connects the power cord to the printer.
C USB port
Connect the USB cable here.
D Airflow vent
Takes in air to cool the printer internally.
E Lock lever
Releases the lock for the rear cover.
F Rear cover
Open when a paper jam occurs or to perform maintenance.
