Epson Stylus Photo R3000 Service Manual

Adjustment Required Adjustments 34
Epson Stylus Photo R3000 Revision A
Confidential
Note 1: The adjustment is not necessary for the parts other than mentioned.
2: Make sure to perform the adjustment using the Adjustment Program after mechanism adjustment is complete.
(See “ Table2-2 Required Adjustment List (Adjustment Program) (p35)” for the details.)
Note "*1": The adjustment is not necessary if you mark the installing positions of the LD Roller Guides before removing them, and align the markings
when installing the LD Roller Guides.
"*2": Only removing/replacing the Mist Board is included.
Table 2-1. Required Adjustment List (Mechanism Adjustment)
Adjustment Type Mechanism adjustment
Priority 1 2 3 4 5
Adjustment Item
PF Belt Tension
Adjustment
PF Roller Shaft
Center Support
Position Adjustment
ASF Guide Roller
LDs position
adjustment
PG Adjustment
Mist Recovery
check
Purpose
To reduce the load on
the PF motor and to
ensure paper feed
accuracy.
To compensate the
deflection amount on
the PF Roller Shaft
and to maintain the
appropriate paper feed
amount.
To correct the position
of the LD Roller in
order to maintain the
paper feed accuracy.
To secure the
specified clearance
between the print
surface of the
Printhead and paper,
and adjust the
parallelism of the 0-
digit and 130-digit
sides in order to
maintain the print
quality.
To confirm the
voltage applied to the
plate under the Front
Paper Guide Assy is
proper for ink mist
recovery inside the
printer.
Part Name
Printer
Mechanism
Replace
OOOOO
PF Motor
Remove
O --- --- --- ---
Replace
O --- --- --- ---
Printhead
Remove
--- --- --- O ---
Replace
--- --- --- O ---
CR Unit
Remove
--- --- --- O ---
Replace
--- --- --- O ---
LD Roller
Guide
Remove
--- --- O
*1
--- ---
Replace
--- --- O --- ---
Front Paper
Guide Assy
Remove
--- --- --- O O
Replace
--- --- --- O O
PF Roller
Remove
O O --- --- ---
Replace
O O --- --- ---
Mist Board
Assy
*
2
Remove
--- --- --- --- ---
Replace
--- --- --- --- O
How to judge
See “ 2.2.1 PF Timing
Belt Tension
Adjustment (p38)” for
the details.
See “ 2.2.2 PF Roller
Shaft Center Support
Position Adjustment
(TBD) (p39)” for the
details.
See “ 2.2.3 ASF Guide
Roller LDs position
adjustment (p44)” for
the details.
See “ 2.2.4 PG
Adjustment (p47)” for
the details.
See “ 2.2.5 Mist
Recovery check
(p51)” for the details.
Adjustment program
--- --- --- --- ---
Tool
(See p 38) (See p 39) (See p 44) (See p 47) (See p 51)

Epson Stylus Photo R3000 Specifications

General

Color	Yes
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Interface	USB 2.0
Print technology	Inkjet
Dimensions (WxDxH)	614.7 x 368.3 x 228.6 mm
Networking features	100Base-TX Ethernet
Paper tray media types	Photo paper, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A3
Compatible operating systems	Windows 7 (32-bit, 64-bit), Windows Vista (32-bit, 64-bit), Windows XP, Windows XP Professional x64 Mac OS X 10.5.x – 10.6.x
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Sustainability certificates	ENERGY STAR
Power consumption (standby)	3.5 W
Power consumption (printing)	21 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Sound power level (printing)	38 dB
Country of origin	China
Market positioning	Home & office
Pallet width	800 mm
Pallet height	2150 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	10 pc(s)
Quantity per pallet layer	2 pc(s)
Package depth	750 mm
Package width	490 mm
Package height	400 mm
Package weight	19420 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	368.3 mm
Width	614.7 mm
Height	228.6 mm
