Epson Stylus Photo R3000 Service Manual

Confidential
Appendix Connector Diagram 73
Epson Stylus Photo R3000 Revision A
4.2 Connector Diagram
Cable connections of this printer are shown below.
Figure 4-2. Connector Diagram
MK
PK
LKLLK
C
VMLC
VLM
Y
CN2
CN6
CN4
CN5
CN1
CN1
CN20
CN22
CN115
CN116
CN117
CN118
CN119
CN3
CN4
CN2 CN1
CN5
CN4CN5
J1
CN7
CN3
CN30
CN35
CN13
CN2
CN60
CN19 CN15 CN2
CN1CN1CN1
CN9CN8 CN11 CN12CN10
CN1
CN1 CN2
CN1
CN2
CN2
CN5
CN6
CN6
PE Sensor
PF Encoder
APG Position Sensor
APG/HP Sensor
ASF Relay Board
(CA58SUB-B)
Tray Detector
Roll Paper Guide Open Senso
r
Decomp Pump Motor
CR Motor
PF Motor
Pump Motor
APG Motor
ASF Motor
I/C Holder Cover Open Sensor
Cover Open Sensor
Panel Board
(CA86PNL)
LCD
Wireless LAN Module
Main Board
(CA86MAIN)
USB
Ethernet
PictBridge
Front Paper Guide Assy
Mist Board
(CA86SUB-D)
CN1CN3
AC in
Power Supply Board
(CA86PSB/CA86PSE)
Printhead
CSIC
CR Contact
Module
CR Unit
I/C Holder Unit
CR Contact
Module
CR Contact
Module
CR Relay Board
(CA86SUB)
CR Encoder Board
PW Sensor
Ink Selector Sensor
Ink Selector Motor

Epson Stylus Photo R3000 Specifications

General

Color	Yes
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Interface	USB 2.0
Print technology	Inkjet
Dimensions (WxDxH)	614.7 x 368.3 x 228.6 mm
Networking features	100Base-TX Ethernet
Paper tray media types	Photo paper, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A3
Compatible operating systems	Windows 7 (32-bit, 64-bit), Windows Vista (32-bit, 64-bit), Windows XP, Windows XP Professional x64 Mac OS X 10.5.x – 10.6.x
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Sustainability certificates	ENERGY STAR
Power consumption (standby)	3.5 W
Power consumption (printing)	21 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Sound power level (printing)	38 dB
Country of origin	China
Market positioning	Home & office
Pallet width	800 mm
Pallet height	2150 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	10 pc(s)
Quantity per pallet layer	2 pc(s)
Package depth	750 mm
Package width	490 mm
Package height	400 mm
Package weight	19420 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	368.3 mm
Width	614.7 mm
Height	228.6 mm
