Reference Information 4-7
Notes on slip paper
❏
The slip paper must be flat, without curls or wrinkles,
especially at the top edges. Otherwise, the paper may rub
against the ribbon and become dirty.
❏
There must be no glue on the bottom edge. Choose slip paper
carefully since paper feeding and insertion are affected by
gluing conditions (such as glue quality, method, and length)
and glue location (see the illustration below). Be especially
careful when slip paper is wide and has glue on the left edge,
since it may not feed in a straight line.
.
❏
Since the BOF sensor uses a photo detector, do not use paper
that has holes at the detector position, or is translucent.
Paper feed direction Glued area
OK to use
Do not use
Use carefully
OK to use
