A-4 Dip Switch and Paper Near End Settings

Parallel interface specification

Set 1

Set 2

SW Function ON OFF

1-1 Auto line feed Always enabled Always disabled

1-2 Receive buffer capacity 45 bytes 4K bytes

1-3 ~

1-8

Undefined — —

SW Function ON OFF

2-1

Handshaking (BUSY

condition)

•Receive buffer full

•Reading data

•Off-line

•Receive buffer full

•Reading data

2-2

Reserved

(Do not change settings)

Fixed to Off

2-3

Selects print density Refer to table below

2-4

2-5 ~

2-7

Reserved

(Do not change settings)

Fixed to Off

2-8

I/F pin 31 reset signal

(Do not change settings)

Fixed to On
