A-2 Dip Switch and Paper Near End Settings
Print Density and Low Power consumption mode selection (Only
for Receit)
Transmission Speed
Transmission Speed (BPS)-bits per second 1-7 1-8
2400 ON ON
4800 OFF ON
9600 ON OFF
19200 OFF OFF
Set 2
SW Function ON OFF
2-1
Handshaking (BUSY
condition)
Receive buffer full
Off line or
receive buffer full
2-2
Customer display
(DM-D) connection
Connected Not connected
2-3
Selects print density Refer to table below
2-4
2-5 Reserved: do not change settings
Fixed to OFF
2-6
2-7 I/F pin 6 reset signal Enabled Disabled
2-8 I/F pin 25 reset signal Enabled Disabled
Print Density SW 2-3 SW 2-4
Low power consumption mode ON ON
1 (Light) OFF OFF
2ONOFF
3 (Dark) OFF ON
H5poar2.fm Page 2 Tuesday, July 14, 1998 12:34 PM
