Chapter 1 Product Overview
1
Control panel
1 Power LED Lights up when the printer is turned on.
Flashes during head cleaning and other operations such as when turning the printer on/off.
2 Error LED Lights up when the printer is offline due to the following conditions.
The ink cartridge is not installed or requires replacement.
The roll paper has run out.
The Front cover/Roll paper cover is open.
During power-on initialization.
During power-off processing.
When the printer is waiting for printing or insertion of another slip to be printed while the
printer is waiting for removal of a slip paper.
Off when the printer is online.
Flashes when an error occurs. (See
"Error LED is On/Flashing" on page 86.)
3 Cut sheet LED Lights up when slip paper (cut sheet) is selected as the print sheet.
Off when roll paper is selected as the print sheet.
Flashes when the printer is in the slip paper insertion or removal waiting state.
4 Paper LED Lights up when the roll paper has run out or is near the end.
5 Ink LED Lights up when the ink cartridge is not installed or requires replacement.
Off when the ink cartridge is installed and there is sufficient ink. Flashes when the ink is low.
6 Feed Button Press this button to feed the roll paper or slip paper.
Paper cannot be fed using this button in the following cases:
The Front cover/ Roll paper cover is open.
Printer is in the slip paper insertion or removal state.
When head cleaning is being performed or an error has occurred with any sheet selected.
7 Cleaning Button Press this button for more than three seconds to perform head cleaning.
