Epson TM-L90 series - Appendix B Overview of the Mechanisms

Rev.B Overview of the Mechanisms Appendix B-1
TM-L90 Service Manual
Confidential
Appendix B
Overview of the Mechanisms
This printer consists of the next four units:
❏ Cover unit
❏ Print/paper feed unit
❏ Paper supply unit
❏ Autocutter unit
The illustration below shows an external view of the printer mechanism:
Cover unit
aper supply unit
Print/paper feed unit
Autocutter unit
