Table C-1 Tools
Tool Specifications Purpose Source
Torque-limiting hexagon box driver Tip size: 5 mm
The tightening
torque for the nut
should be
between 34.3 to
39.2 Ncm (3.5 to
4.0 kgcm).
Remove and install the paper
feed motor
Use commercially
available product.
Crosshead screwdriver No. 0, 1, 2 Disassembly and assembly Use commercially
available product.
Flathead screwdriver — Disassembly and assembly Use commercially
available product.
Tweezers — Disassembly and assembly Use commercially
available product.
Wrist strap
(static electricity countermeasure)
— Disassembly and assembly Use commercially
available product.
E-ring holder 1.5, 3 Disassembly and assembly Use commercially
available product.
