Epson TM-L90 series - Reference Number List

Appendix D-6 Parts List Rev.C
Confidential
Reference Number List
Table D-2 Reference number list
Ref.# Name for service manual Name for price list Q’ty Note
101 NE detector adjustment screw SCREW,DETECTOR ADJUSTMENT, N.E. 1
102 Logo plate LOGO PLATE,AB 1
103 Head caution seal SEAL,CAUTION,HEAD B 1
104 Fixed blade holder spring SPRING,BLADE HOLDER 1
105 Switch screw SCREW,SWITCH,1 2
106 Caution seal SEAL,CAUTION,C 1
107 Frame R FRAME,R 1
108 Front frame FRAME,FRONT 1
109 Frame strengthening plate R PLATE,FRAME STRENGTHEN,R 1
110 Frame strengthening plate L PLATE,FRAME STRENGTHEN,L 1
111 Circuit board frame FRAME CIRCUIT BOARD,A 1
112 BM detector holder HOLDER,BM DETECTOR 1
113 Spring holder plate PLATE,SPRING HOLDER 1
114 Fixed blade FIXED BLADE 1
115 Reduction gear C GEAR,REDUCTION,C 1
116 Reduction gear D GEAR,REDUCTION,D 1
117 Paper feed motor damper DAMPER,PAPER FEED MOTOR 3
118 Motor ground plate GROUND PLATE,MOTOR 1
119 Center frame FRAME,CENTER 1
120 Label paper holder HOLDER,LABEL 1
121 LED holder assembly HOLDER,LED ASSEMBLY 1
122 Paper holding roller ROLLER,PAPER HOLD 8
123 Tension plate spring SPRING,TENSION PLATE 2
124 Cover leaf spring PLATE SPRING,COVER 1
125 Head holder spring SPRING,HEAD HOLDER 2
126 Label paper guide GUIDE,LABEL 1
127 Hinge cover COVER,ARM,AA 1
128 Cover open lever LEVER,COVER OPEN 1
129 Lever shaft SHAFT,LEVER 1
130 Lever button BUTTON,LEVER,AA 1
131 Feed button BUTTON,FEED,AA 1
132 Feed spacer SPACER,FEED 1
133 Cover rotation shaft SHAFT,COVER TURNING 2
134 Switch panel holder HOLDER,SWITCH PANEL 1
