Rev.C Parts List Appendix D-5
TM-L90 Service Manual
Confidential
Paper outlet tape TAPE,PAPER OUTLET 1 175 Accessory
Plain washer (W1) PLAIN WASHER — W1
Platen assembly PLATEN ASSEMBLY 1 163
Power switch cover COVER,POWER SWITCH,AA 1 157 Accessory
Reduction gear C GEAR,REDUCTION,C 1 115
Reduction gear D GEAR,REDUCTION,D 1 116
Roll paper cover assembly COVER,ROLL PAPER ASSEMBLY,BA 1 152
Rubber foot A RUBBER FOOT,A 4 140
Rubber foot C RUBBER FOOT,C 4 159
Screw (S1) C.B.P-TITE,3X10,F/ZN — S01
Screw (S10) C.C.S. SCREW — S10 Accessory
Screw (S2) C.C.P-TITE SCREW,3X8,F/ZN — S02
Screw (S3) C.B.B.SCREW,4X12,F/ZN — S03
Screw (S4) C.B.S. SCREW — S04
Screw (S5) C.B.S. SCREW — S05
Screw (S6) C.P.S.(O) SCREW — S06
Screw (S7) C.B.B-TITE SCREW — S07
Screw (S9) C.B. SCREW — S09
Shield plate PLATE,SHIELD 1 180
Spacer SPACER,3x4x4 3 153
Spacer B SPACER,B
2
178
Spacer guide plate PLATE,SPACER GUIDE 1 171
Spacer guide shaft SHAFT,SPACER GUIDE 1 170
Spacer (3X4X4) SPACER,3X4X4,F/ZN 3 153
Spring holder plate PLATE,SPRING HOLDER 1 113
Sub circuit board assembly SUB CIRCUIT BOARD ASSEMBLY,AA 1 209
Switch circuit board assembly SWITCH CIRCUIT BOARD ASSEMBLY,AA 1 210
Switch circuit board FFC FFC,SWITCH CIRCUIT BOARD 1 208
Switch panel holder HOLDER,SWITCH PANEL 1 134
Switch panel label LABEL,SWITCH PANEL,BA 1 158 Accessory
Switch screw SCREW,SWITCH,1 2 105
Tension plate spring SPRING,TENSION PLATE 2 123
Thermal print head assembly THERMAL PRINT HEAD ASSEMBLY,C 1 147
Table D-1 Alphanumeric list
Name for service manual Name for price list Q’ty Ref.# Note
To Next Page
