Appendix D
Parts List
Alphanumeric List
Table D-1 Alphanumeric list
Name for service manual Name for price list Q’ty Ref.# Note
Autocutter unit AUTO CUTTER UNIT 1 162
Auxiliary holder plate PLATE,HOLDER AUXILIARY 1 169
BM detector holder HOLDER,BM DETECTOR 1 112
BM paper detector circuit board
assembly
CIRCUIT BOARD,BM PAPER DETECTOR
ASSEMBLY
1 213
Bottom plate PLATE,LOWER 1 165
Caution seal SEAL,CAUTION,C 1 106
Center frame FRAME,CENTER 1 119
Circuit board frame FRAME CIRCUIT BOARD,A 1 111
Connector cover COVER,CONNECTOR,AA 1 141
Cover detector assembly COVER,DETECTOR ASSEMBLY 1 166
Cover leaf spring PLATE SPRING,COVER 1 124
Cover open lever LEVER,COVER OPEN 1 128
Cover rotation shaft SHAFT,COVER TURNING 2 133
Cover tape TAPE,COVER 1 160 Accessory
Cutter cover COVER,CUTTER,AA 1 139
Cutter frame assembly FRAME,CUTTER ASSEMBLY 1 149
Cutter motor sub-assembly MOTOR,CUTTER SUB ASSEMBLY 1 151
NE detector adjustment screw SCREW,DETECTOR ADJUSTMENT, N.E. 1 101
DIP switch cover COVER,DIP SWITCH 1 154
E-ring (E1) RETAINING RING — E1
E-ring (E2) RETAINING RING — E2
FEED button BUTTON,FEED,AA 1 131
Feed sheet SHEET,FEED,A 1 135
Feed spacer SPACER,FEED 1 132
Ferrite core FERRITE CORE 1 211
Fixed blade FIXED BLADE 1 114
Fixed blade holder spring SPRING,BLADE HOLDER 1 104
Frame L assembly FRAME,L ASSEMBLY,A 1 142
