Rev.C Parts List Appendix D-7
TM-L90 Service Manual
Confidential
135 Feed sheet SHEET,FEED,A 1
136 Main case assembly CASE,MAIN ASSEMBLY,AA 1
139 Cutter cover COVER,CUTTER,AA 1
140 Rubber foot A RUBBER FOOT,A 4
141 Connector cover COVER,CONNECTOR,AA 1
142 Frame L assembly FRAME,L ASSEMBLY,A 1
144 NE detector lever LEVER,N.E.DETECTOR 1
145 NE detector holder HOLDER,N.E.DETECTOR 1
146 Micro switch MICRO-SWITCH 1
147 Thermal print head assembly THERMAL PRINT HEAD ASSEMBLY,C 1
148 Manual cutter screw SCREW,MANUAL CUTTER 3
149 Cutter frame assembly FRAME,CUTTER ASSEMBLY 1
150 Paper cutter cover assembly COVER,PAPER CUTTER ASSEMBLY,B 1
151 Cutter motor sub-assembly MOTOR,CUTTER SUB ASSEMBLY 1
152 Roll paper cover assembly COVER,ROLL PAPER ASSEMBLY,BA 1
153 Spacer (3X4X4) SPACER,3X4X4,F/ZN 3
154 DIP switch cover COVER,DIP SWITCH 1
155 Handling label LABEL,OPERATION,BA 1
156 Label paper platen holder HOLDER,LABEL PLATEN 1
157 Power switch cover COVER,POWER SWITCH,AA 1 Accessory
158 Switch panel label LABEL,SWITCH PANEL,BA 1 Accessory
159 Rubber foot C RUBBER FOOT,C 4
160 Cover tape TAPE,COVER 1 Accessory
162 Autocutter unit AUTO CUTTER UNIT 1
163 Platen assembly PLATEN ASSEMBLY 1
164 Paper feed roller shaft holder SHAFT HOLDER,PAPER FEED ROLLER 1
165 Bottom plate PLATE,LOWER 1
166 Cover detector assembly COVER,DETECTOR ASSEMBLY 1
167 Manual cutter MANUAL CUTTER 1
169 Holder auxiliary plate PLATE,HOLDER AUXILIARY 1
170 Spacer guide shaft SHAFT,SPACER GUIDE 1
171 Spacer guide plate PLATE,SPACER GUIDE 1
172 Hinge spacer SPACER,HINGE 2
173 Label paper spacer SPACER,LABEL 1 Accessory
174 Paper outlet guide GUIDE,PAPER OUTLET,AA 1 Accessory
175 Paper outlet tape TAPE,PAPER OUTLET 1 Accessory
Table D-2 Reference number list
Ref.# Name for service manual Name for price list Q’ty Note
