Appendix D-8 Parts List Rev.C
Confidential
178 Spacer B SPACER,B
2
179 Mini-clamp MINI CLAMP 1
180 Shield plate PLATE,SHIELD 1
201 Main circuit board unit MAIN CIRCUIT BOARD UNIT 1
202 I/F circuit board unit I/F CIRCUIT BOARD UNIT 1
205 Paper feed motor MOTOR,PAPER FEED,B 1
206 NE detector lead wire LEAD WIRE,N.E.DETECTOR 1
207 Head FFC FFC,HEAD 1
208 Switch circuit board FFC FFC,SWITCH CIRCUIT BOARD 1
209 Sub circuit board assembly SUB CIRCUIT BOARD ASSEMBLY 1
210 Switch circuit board assembly SWITCH CIRCUIT BOARD ASSEMBLY 1
211 Ferrite core FERRITE CORE 1
213 BM paper detector circuit board
assembly
CIRCUIT BOARD,BM PAPER DETECTOR
ASSEMBLY
1
E1 E-ring (E1) RETAINING RING —
E2 E-ring (E2) RETAINING RING —
N1 Nut (N1) HEXAGON NUT —
S01 Screw (S1) C.B.P-TITE,3X10,F/ZN —
S02 Screw (S2) C.C.P-TITE SCREW,3X8,F/ZN —
S03 Screw (S3) C.B.B.SCREW,4X12,F/ZN —
S04 Screw (S4) C.B.S. SCREW —
S05 Screw (S5) C.B.S. SCREW —
S06 Screw (S6) C.P.S.(O) SCREW —
S07 Screw (S7) C.B.B-TITE SCREW —
S09 Screw (S9) C.B. SCREW —
S10 Screw (S10) C.C.S. SCREW — Accessory
W1 Plain washer (W1) PLAIN WASHER —
Table D-2 Reference number list
Ref.# Name for service manual Name for price list Q’ty Note
To Next Page
