Chapter 1 Product Overview
21
1
Printing Specifications
dpi: dots per inch
*1: when the printer prints with the default print density level at 24V and 25°C {77°F}.
Printing method Thermal line printing
Dot density 180 × 180 dpi
Printing direction Unidirectional with friction feed (Reverse feed is not
supported.)
Maximum printable width 72.2 mm, 512 dots
Character
per line
Font A (12 × 24) 42
Font B (9 × 17) 56
Maximum
print speed*
1
High speed mode 170 mm/s
Low power consumption
mode
150 mm/s
Line spacing 4.23 mm {1/6"} (Factory setting, programmable by
command)
• Printing speed may be slower, depending on the such items as the data transmission
speed.
• High speed mode/low power consumption mode can be shifted with a DIP switch
(2-3/2-4).
