Epson TM T70 Technical Reference Guide

Chapter 2 Setup
35
2
For Interfaces Other Than Serial Interface
The following DIP switch functi ons are for the parallel/USB/LAN/wireless LAN interface.
DIP switch bank 1
DIP switch bank 2
SW Function ON OFF
Factory
setting
1-1 Auto line feed Always enabled Always disabled OFF
1-2 Receive buffer capacity 45 bytes 4 KB OFF
1-3 Reserved — — OFF
1-4 Error signal output 7 bits 8 bits OFF
1-5 ∼
1-8
Reserved — — OFF
SW Function ON OFF
Factory
setting
2-1 Handshaking (BUSY condition) Receive buffer full
• Offline
• Receive buffer full
OFF
2-2
Reserved (Do not change
settings)
Fixed to OFF OFF
2-3 ∼
2-4
Selects print density/Low
power consumption mode
See "Selecting the Print Density (DIP Switch
2-3/2-4)" on page 36.
OFF
2-5 Reserved — — OFF
2-6 ∼
2-7
Reserved (Do not change
settings)
Fixed to OFF OFF
2-8
IF pin 31 reset signal (Do not
change settings)
Fixed to ON ON
• For DIP switch 2-1 (BUSY condition), see also "Selecting the BUSY Status" on page 37.
• Do not change the setting of DIP switches 2-2, 2-6, and 2-7. Otherwise, the printer may
not operate normally.

Epson TM T70 Specifications

General

Resolution	180 dpi
Auto Cutter	Yes
Print Method	Thermal line
Paper Width	79.5 ±0.5 mm
Interface	USB, Ethernet
Power Supply	AC adapter
