Chapter 2 Setup
43
2
Connecting the USB interface cable
1
Attach the locking wire saddle at the location shown in the figure below.
2
Put the USB cable through the locking wire saddle.
3
Connect the USB cable from the host computer to the USB upstream
connector.
Putting the USB cable through the locking wire saddle, as shown in the figure below,
prevents the cable from coming unplugged.
UB-board
Locking wire saddle
USB cable
USB upstream connector
