TM-U220II User’s Manual 19
English
US (for Type B and Type D printer)
*: If you set DIP Switch 1-1 to On (Right side up printing mode), make sure to set DIP Switch 1-2 to Off (Receive buffer
capacity: 20 KB).
Serial interface (DIP Switch 1)
SW Function On Off
1 Printing mode Right side up
printing mode
Normal
printing
mode
2 Receive buffer capacity 40 bytes 20 KB
3 Handshaking XON/XOFF DTR/DSR
4 Word length 7 bits 8 bits
5 Parity check Yes No
6 Parity selection Even Odd
7 Transmission speed 4800 bps 9600 bps
8
BUSY condition Receive buffer
full
Receive
buffer full or
Offline
Serial interface (DIP Switch 2)
SW Function On Off
1 Print column 42/35 40/33
2 For internal use only
(autocutter)
Enabled Disabled
3 Pin 6 reset signal Used Not used
4 Pin 25 reset signal Used Not used
5 Undefined - -
6 For internal use only
(flash memory rewriting)
Enabled Disabled
7 Undefined - -
8 Serial interface selection Memory
switch
DIP switch
Other interfaces (DIP Switch 1)
SW Function On Off
1 Printing mode Right side up
printing mode
Normal
printing
mode
2 Receive buffer capacity 40 bytes 20 KB
3–7 Undefined - -
8 BUSY condition Receive buffer
full
Receive
buffer full or
Offline
Other interfaces (DIP Switch 2)
SW Function On Off
1 Print column selection 42/35 40/33
2 For internal use only
(autocutter)
Enabled Disabled
3 Undefined - -
4 Wired LAN, parallel: pin 31
reset signal
Used Not used
USB-B: Undefined - -
5 Undefined - -
6 For internal use only (flash
memory rewriting)
Enabled Disabled
7 Undefined - -
8 Undefined - -
