9 • Troubleshooting
60 / 144
Art.-Nr.: 80116-271
04.06
Status of ERROR list: 08.04
A/E-Errors
Recognizing module: A = APC, E = Extension module VEM 2
Recog-
nizing
module
Error
code
Additional infor-
mation
Description Remedy
A 1 Timeout of activation sig-
nal.
Ensure uninterrupted CAN
transmission (e.g. shielded
FS cable or position of FS
cable to HF cable).
If reproducible error: Carry
out CAN analysis (e.g.
PCAN explorer).
A/E 2 APC setup parameters
invalid.
Information, analyse CAN
data (sector error).
A/E 3 Position of safety relays
IIF1.
Relay on IIF module 1 or
control on APC controller
faulty.
A/E 4 Safety relay IIF2 is
addressed via relay 1+i.
Relay on IIF module 2 or
control on APC controller
faulty.
A/E 5 Button error receptacle 1. Short circuit or interruption
to/on receptacle board
1,
check connector.
A/E 6 Button error receptacle 2. Short circuit or interruption
to/on receptacle board
2,
check connection.
A 7 Valve error. Input valve coil is not
inserted or is faulty, check
connection.
A 8 Interruption - proportional
valve.
Proportional valve coil is
not inserted or is faulty,
check connection.
A 9 Short circuit - proportional
valve
Short circuit in proportional
valve circuit.
A A Control transistor - propor-
tional valve.
Control transistor faulty.
A/E B Error in test mode. Error during calibration or
diagnosis, mostly caused
by PC program. Mostly
uncritical.
