Ercolina HB60 - Commissioning Procedures; Workspace Requirements for Operation

-13-
05/2021 HB60
Hazard: it is strictly forbidden to lift the machine with any means other than forklifts, as shown
in Figure 4.
Figure 4 - Incorrect handling
3. Commissioning
3.1. Workspace
The minimum space necessary for using the HB60 machine can be calculated based on the length of
the material to be processed: to obtain it, refer to what is shown in Figure 5. Be very careful to allocate
enough space in order to ensure the materials can be handled near the machine.
Figure 5 - Space necessary for using the HB60 machine
