1. General notes
1.1. Technical data
Operating Range
Resistance module cm3 12
Bending capacity (A53 Grade
A)
Inch 2” Schedule 40 Pipe
Minimum external diameter Inch ¼”
Minimum bending radius Inch 1.4”
Maximum bending radius Inch 10.7
Maximum bending angle Degrees 210°
Bending direction - Counter-clockwise
Electrical power supply
Power kW 0.75
Voltage V
120V 1ph standard;
220V 1ph or 480V 3ph on
request
Mains frequency Hz 50-60
Dimensions, weight, other data
Maximum length (approxi-
mate)
Inch 29” (machine with cabinet)
Maximum width (approximate) Inch 18.5” (machine with cabinet)
Height (approximate) Inch 40” (machine with cabinet)
Weight (approximate) Pound 450 Pounds
Sound pressure level DB <60
Oil volume in the tank L 10
